Design for high quality cutting users only :

• Using the most advanced IGBT technology design, easy arc, fast cutting speed, smooth cut, the power supply is designed with high rated duty cycle, over 50% when temp. is 40'c;
• Certified to EU(CE) and China Compulsory Certification (CCC)

Specifications：

• Voltage(V) : 230V
• Frequency(Hz) : 50-60
• Input Power(KVA) : 6.2
• No-Load voltage(V) : 250V
• Current range(A) : 20-40A
• Rated duty cycle : 60%
• Quality cutting thickness : 7
• Max. cutting thickness : 12
• Proper cutting air pressure : 4~6
• Power factor : 0.73
• Efficiency(%) : 85
• Insulation grade : F
• Protection grade : IP21S
• Weight(kg) : 6
• L x W x H(mm) : 375 x 155 x 235
